With our SAG calculator, you can easily determine the sagitta using only two inputs: the circle’s radius and the diameter.

This tool is designed to enhance your understanding of:

What SAG is and the definition of SAG;
How to calculate suspension SAG; and
The application of suspension SAG.

We have also included practical examples to help you comprehend the process of calculation using the SAG formula.

To explore related tools, check out our resuspension calculator and diameter calculator.

What is SAG? SAG definition

SAG refers to the depth or drop of a curved line, essentially, how far the arc deviates from a straight line connecting its endpoints. It’s a concept used in various fields, from designing suspension systems for vehicles to crafting elegant architectural arches. By understanding SAG, you can better appreciate how curvature impacts performance and aesthetics.

This tool is designed to make it easy to grasp the underlying idea of SAG and apply it to practical scenarios without getting bogged down in the mathematical details.

How to calculate SAG

Now that we understand what SAG is, let’s explore an example to better understand how to calculate it.

Let’s assume the following:

Radius of curvature (R): 10 m
Diameter (d): 13 m

Compute the radius of the curvature.

The first step is to determine the radius of the curvature. For our example, the radius of the curvature is 10 m.

To understand this calculation better, you can use our radius of a circle calculator.
Determine the diameter.

Next, you can compute the diameter. In this instance, the diameter is 13 m.
Calculate the SAG.

The final step is to calculate the SAG using the following formula:

\quad \begin{split} \text{sag} &= R - \sqrt{R^2 - \left(\frac{d}{2}\right)^2}\\[1.4em] &= 10 - \sqrt{10^2 - \left(\frac{13}{2}\right)^2}\\[1.4em] &= 2.4007 \end{split}

Why is SAG important?

SAG is a crucial measurement because it determines the depth or curvature of an arc relative to its chord. In practical applications, such as suspension systems, having the correct sag is essential for ensuring that the suspension operates within its optimal range.

This balance helps maintain consistent wheel contact with the road, which in turn improves traction, ride comfort, and overall handling. Whether you're tuning a vehicle's suspension for performance or designing an architectural arch for both aesthetics and strength, understanding and accurately calculating SAG plays a vital role in achieving the desired outcome.
